Membrane Filter Press Cloth Polypropylene Non Woven Filter Fabric 30 Micron ​

Press filter cloth description

Press filter cloth has always been a crucial component in the press filters. It’s quality and correct selection decides the throughput and filtration performance. Nowadays 98% of the press filtration equipment using filter cloth as the filter medium. The press filter cloth has obvious widely range applicability and serviceability.

The press filter cloth also has diverse weaving type to obtain different particle retain and filter cake discharge capacity.

For instance, press filter cloth in twill weave has more smooth surface than plain weave for easy cake release and larger aperture for dewatering and anti-blinding. It’s suitable for high viscosity slurry.

Press filter cloth
There are three types of the vertical filter press – Chamber press filter, Plate & frame press filter, and Membrane press filter. Even though the press filter cloth for the three above are all quadrate, they are different.

The press filter cloth for membrane and chamber press filter are the same, connect two pieces of square filter cloth by the central neck tube, and the cloth for plate & frame press filter is a single square piece with open circular space at the corresponding position.

How to choose the filter press cloth for your press filters?

1) Select the material: According to the filtrate chemical and physical properties to choose the ideal material of the press filter cloth, see synthetic fiber chemical & physical properties.
2) Select the fiber: There are monofilament, multifilament, short fiber, etc. of filter press cloth for press filters, the fiber influence the filtration performance, strength, regeneration, and other properties.
3) Choosing the right weave pattern
The weave pattern affects the precise, cake discharge and cloth regeneration performance.
4) Cloth after-treatment, heat set treatment
5) Filtration experiment on the raw materials slurry is important after the preliminary selection of the filter press cloth. A sample experiment was carried out on the material filtration to check the filtration rate, retention performance, filter cake moisture content, cake release performance, regeneration properties, etc.

Our company’s products mainly include:high temperature filter material,non-woven needle felt,dust collect filter bag,woven filter cloth,vacuum filter belt,air slide fabric,polyester fabric,sludge dehydrating belt and high density stainless steel mesh screen,our quality had reached international standard and leader level in filter industry.

Huading Group is a group company with 4 independent professional factories, including Zhejiang Huading Environmental Technology Co., Ltd./Zhejiang Huading Mesh Industry Co., Ltd./Zhejiang Huading Filter Material Co., Ltd./Hangzhou Huading Environmental Technology Co., Ltd.

HUADING has been deeply involved in the field of polyester mesh for more than 20 years. Its core business covers non-woven fiber mesh curtains, power plant desulfurization mesh, polyester mesh, filter press filters, liquid filter bags, woven filter cloth, dust removal bags, and filter cartridges. and other products.

The company has long been committed to providing high-quality filter media products and services to domestic and foreign customers. Its business scope covers more than 50 countries and regions around the world, including the United States, Australia, Japan, Russia, and Germany.

Our company's products mainly include: high-temperature filter material, non-woven needle felt, dust filter bag, woven filter cloth, vacuum filter belt, air slide cloth, polyester cloth, sludge dewatering belt, high-density stainless steel screen, our quality It has reached the international standard and leading level of the filtration industry.

Our products are widely used in power plants, ferrous metallurgy, cement plants, petrochemicals, waste incineration, dust removal and air filtration.

HUADING owns the Zhejiang Provincial Enterprise Technology Center and the "Filtration Material Engineering Technology Center" of China's petrochemical industry.
It has passed GB/T29490 intellectual property management system certification, ISO9001 quality management system certification, ISO14001 environmental management system certification, and OHSAS18001 occupational health and safety management system certification.
